• Model NO.：JT-16
• Speed：15000rpm
• Weight：5.5kg
• Transport Package：4kg
• Specification：193*165*82mm
• Trademark：VIMEL
• Origin：China(Mainland)
• Production Capacity：50000piece,Year

Voltage220V/50Hz±10%     110V/60Hz±10%Power100WSpeed15000rpmSize16*16*33cmWeight5.5kgDrill diameterφ3 * φ1.85, φ3 * φ1.95

Product use:

Good grounding plug AC 220V power supply, close the power switch power indicator light, and the red laser dot lights (φ1 ~ φ1.5). Just adjust the desired drilling depth, put a plaster model can be carried out drilling. Special Note: When the plaster model placed bench laser pinpoint holes, be sure to plaster model with both hands gripping the table together, and press down until the drilling is completed, together again on the rise reset. Midway must not let go, otherwise it will be easy to break or drill holes and allowed too large.



how to replace the laser head:

Unplug the power cord, open the bottom cover; loosen the laser head pin screws, pull out the laser head, careful not to pull off the back of the wire (the other hand on the inside line feed); cut the laser head is connected to the back of the wire, the wire red and white, white and red cut line than 20mm, were set into the heat-shrinkable tube with two new red and white line color laser welding head, then heated shrink tubing (hair dryer or an open flame can) make tight package to shrink; front-line delivery, pull back, push the laser head vertically into the hole and tighten the pin screws; power light, if slight deviations from the table plate removed, then four motor fixing Loosen the screws (do not twist off), adjust the center and then tighten the screws, respectively.



How to replace the drill:
Turn off the power, remove the rubber cartridge. With high spindle wrench flat root port, low chuck wrench housing flat mouth, loosen the screw to replace the drill bit, proof depth with two wrenches to tighten.
