• Model NO.：LK-C65
• Certificate：CE ISO FDA
• Sensor Technology：Aps CMOS Sensor
• Sensor Active Area：30*22.5(Hdr-500)
• Additional：Twain Driver
• Weight：2.0kgs,Set
• Sensor Size：38.5*27.5*6mm
• Exterior Material：Sillicone
• Sensor Thickness：6mm
• Dynamic Range：0~4, 096
• Image Transfer：USB2.0
• Cable Length：>3m
• External Dimension (mm)：40*26(Hdr-500)
• Environment Temperature：+10degree~+40degree
• Environment Relative Humidity：<95%
• Transport Package：Carton
• Specification：27.5*38.5mm
• Trademark：Handy
• Origin：China
• HS Code：90184990
• Production Capacity：1000 PCS,Year

SensorAPS CMOS sensor External dimension (mm)44×32(HDR-600) ; 40×26(HDR-500) Sensor Active Area36×27(HDR-600) ; 30×22.5(HDR-500) Sensor Thickness6mm Dynamic Range0~4,096 Power5V±0.5V Image TransferUSB2.0 Cable Length≥ 3m



Operating conditions:

Environment Temperature : +10ºC~+40ºC
Environment relative humidity : ≤95%;
Air pressure : 860hPa~1060hPa;
Transport and Storage conditions:
Environment Temperature: -25ºC~+60ºC;
Environment relative humidity : 10%~93%;
Air pressure : 860hPa~1060hPa;
