• Model NO.：1151503000
• Input Voltage：100V-240V.50,60 Hz
• Supply Voltage：DC30V 1.3A
• Input Power：30va-48va
• Output Power：3W-20W
• Fuse：T3al 250V
• Operation Mode：Continuous Operation
• Type of Electric Shock Protection：Class II
• Transport Package：Carton for Dental Scaler
• Specification：Q6
• Trademark：VRN
• Origin：Henan, China (Mainland)
• Production Capacity：5000 Pieces,Month

Basic Info.

Model NO. 1151503000 Input Voltage 100V-240V.50/60 Hz Supply Voltage DC30V 1.3A Input Power 30va-48va Output Power 3W-20W Fuse T3al 250V Operation Mode Continuous Operation Type of Electric Shock Protection Class II Transport Package Carton for Dental Scaler Specification Q6 Trademark VRN Origin Henan, China (Mainland) Production Capacity 5000 Pieces/Month

Product Description

Scaling & Periodontal & Endodontic Dental Ultrasonic Scaler With Air Polisher

Features for Dental Ultrasonic Scaler with Air Polisher:

1. Dental implant maintaining Sand blasting could remove the plague and stains on the implant  without any harm to the material.Bsides,1 PEEK plastic special implant maintaining tip could offer the soft and high effcient operation.
2. The scaler tip is casted from Titanium alioy to ensure circular vibration track and more concentrated amplitude, so that Perio, Scaling. Endo, Restorative treatments can be done simultaneously.
3. Spray the water and powder mixture onto the tooth surface with compressed air,to remove the dental plaque,pigment and soft dirt,etc, to completely suppress the source of periodontal disease,keep yor gums healthy.
4. During the air polishing treatment,keep the air pressure constant,the doctor can adjust the powder outflow to make patient comfortable and treatment effcient.
5. Two large refilable bottles , satisfy using pure water or disinfectant,and two powder botteltes,double care.
6. The hydraulic routing is made from antiseptic material. Disinfectant for the treatment, such as hydrogen peroxide, chlorhexidine, sodium hypochiorte can be filled into the automatic water supplysystem.
7. Detachable handpiece can be 135ºCand 0.22 MPa autoclave steriization.
8. The evolutional wireless foot pedal remotes the main unit, and the cord foot pedal can also be selected according to user's needs.
9. Soft bright LED light improves the clinical efficiency.



Technical Specifications for Dental Ultrasonic Scaler with Air Polisher:

Period of use	10years
Input Voltage	100V-240V.50/60 Hz
Supply Voltage	DC30V 1.3A
Battery of Wireless Foot Pedal	1.5V two AA batteres
Receiving Sensitivity	114dB(compliance with Telecommunication Act of China) receiving frequency2.4G Hz-2.5G Hz
Primary Tip Vibration Excursion	minimum: 1 μm        deviation:-50% maximum:100 μm    deviation:+50%
Half-excursion Force	minimum: 0.1N        deviation:-50% maximum:2N           deviation:+50%
Tip Vibration Frequency	28 KHz±3KHz
Input Power	30VA-48VA
Output Power	3W-20W
Fuse	T3AL 250V
Intake Pressure	5bar-6 bar(0.5 MPa-0 6 MPa)
Specifications of Sandblasting Powder	The size of sand blasting power which act on gingival is 40 μm-65μm; act on subgingival is 25 μm and brackish or lemon

Weight of Main Unit	1.5 kg
Weight of Power Adapter	0.25kg
Dimension in mm(H x M x D)	310 x 370 x 295
Operation Mode	Continuous operation
Type of Electric Shock Protection	Class II
Capacity of Electric Shock Protection	Applied part, Type B
Degree of protection against harmful ingress of water	Ordinary equipment(IPX4)
Protection against water (used on the foot pedal)	(IPX6)
Security Degree in the Presence of Infammable Anaesthetics or Gases mixed with air or Nitrous Oxide	Not AP or APG Type

Operating Conditions:
a)Ambient temperature:5ºC-40ºC
b)Relative Humidity:≤80%,Atmospheric Pressure:75KPa- 106KPa
c) Supply Voltage:100 V-240V~ 50-60 Hz
d) Wireless Foot Pedal:
Emissive frequency:2 4 GHz- 25GHz,auto hopped frequency
Modulatio GFSK
Efective radiated power:12dbm



Various Accessories:

Main unit *1
Disinfection boxe*2
Powder bottle *2
PH-2 LED ultrasonic piezo handpiece *2
AH-1 supragingival air-polishing handpiece *2
AH-2 subgingival air-polishing handpiece *1
Water Tank *2
Wireless foot pedal *1
Wired foot pedal *1
Wrench of endo file *1
Q6 subgingival air-polishing tip *40
Scaling tips *22
20# Endo file *6
25# Endo file *6
Torque tip wrench *2
Endo File wrench *1
Protective goggles *1
Ultrasonic endo file *1
Anti powder blocking components *1



Packaging and shipping:
1. Mainly packed by carton or other common security package, you also can give us your special requirements about it. We will try our best to make sure the goods arrive safely.
2. Delivery: About 5 days after order confirmed.
3. Freight: The freight cost will charge according to the weight of detailed order.
4. Shipment: Your goods could be shipped to you as your requirement such as by air or by sea, full way tracking for your cargos offered before the arrival of the goods.



Company Information
Baistra Corporation was established in 1998. which is specialized in manufacturing and exporting dental equipment, we have a group of honest, kind, and hard-working people with a thrifty and responsible attitude that has won all our customers' trust .




Why Choose Baistra Company:
1. Professional on dental field for 24 years with advanced facility.
2. Factory price with best quality
3. Accept custom order, available in thickness and package
4. Offer OEM service.
5. Fast service and on-time delivery
6. Sample small quantity sample are available at any time.



Our services:

Pre-sale service:

1. 24 hours online, please feel free to contact us anytime.

2. Provide our customers best quality product.

3. High degree of expertise to solve any problems

After sale service:

1. Fast delivery with tracking number provided to make sure ou can receive your goods fast and safety.

2. Offer free warranty service.

3. Focus on every client's satisfaction. Professional team will solve any problems you may meet In the process of using.



FAQ:

1.Q:Can I have a sample order?
    A:Yes, we welcome sample order to test and check quality.

2.Q:What about the lead time?
   A:Sample needs 3-5 days, mass production needs 1-2 weeks depends on order quantity.

3.Q:How do you ship the goods and how long does it take to arrive?
   A:We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.



Any questions, please send us message freely!
