Tealth Dental Equipment 20: 1 Implant Contra Angle Dental Handpiece

Tealth Foshan Medical Equipment Co., Ltd.
  • Condition：New
  • Certification：TUV, ISO, CE
  • Material：Stainless Steel
  • Light Way：With LED Light
  • Water Way：Outer Channel
  • Usage Times：Non-Disposable

Base Info

  • Model NO.：3203CH
  • Application：Adult, Child
  • Loading Way：Gland Type
  • Head Diameter：Middle Head
  • Exhaust Way：Exhaust Outside
  • Number of Holes：Four Holes
  • Connection：Without Quick Connector
  • Rotating Speed：Low-Speed Handpiece
  • Gear Ratio：20:1 Reduction
  • Noise：Less Than 70dB
  • Max Torque：70n.Cm
  • Max Speed：2,000r,Min
  • Sterilization Temperature：135
  • Transport Package：Plastic Box
  • Specification：Aluminum, stainless steel
  • Trademark：TEALTH
  • Origin：China
  • HS Code：90184100
  • Production Capacity：50000PCS,Year

Description

Basic Info.

Model NO. 3203CH Application Adult, Child Loading Way Gland Type Head Diameter Middle Head Exhaust Way Exhaust Outside Number of Holes Four Holes Connection Without Quick Connector Rotating Speed Low-Speed Handpiece Gear Ratio 20:1 Reduction Noise Less Than 70dB Max Torque 70n.Cm Max Speed 2,000r/Min Sterilization Temperature 135 Transport Package Plastic Box Specification Aluminum, stainless steel Trademark TEALTH Origin China HS Code 90184100 Production Capacity 50000PCS/Year

Product Description

Tealth Dental Equipment 20: 1 Implant Contra Angle Dental Handpiece
Detachable big torque 20:1 implant Surgery dental contra angle

Model:3203CH

Features:
20:1 gear ratio,used in dental implant.
Rotation speed:5-2,000r/min
Push button chuck
Bur applicable:Φ2.35mm
Max torque: 70N.cm
Noise:≤70dB

DESCRIPTION:
Fitting with E type motor , can be avaible to match up with Swiss, Japan, Korea famous brand implant system.
Unfading and Non-slipping
Easy to assemble and split

Tealth Dental Equipment 20: 1 Implant Contra Angle Dental HandpieceTealth Dental Equipment 20: 1 Implant Contra Angle Dental Handpiece
Operation Instruction:
It shall be sterilized before handpiece is used at the first time;Sterilization temperature is 135ºC and last for 12 minutes.
After using,Please follow the instruction to sterilize the handpiece:
1 extract the bur from the handpiece,use the soft brush to clean the dirt and wash with disinfection of alcohol cotton.
2 lubricate the handpiece,pour two drops into air tube one time.
3 wrap it with sterilization package and mark.

Please do not use the acid solution to scrub, inject or soak the handpiece.
Please do not autoclave the handpiece with residual chemical substances.
Handpiece should be packed well and place at clean and dry room without dust, sulfur and salt.
Please do not touch the handpiece immediately after autoclaving.
