• Model NO.：H-X9010DPro
• Imag Dimension(Fov)：12*8cm
• Pixel Size(mm)：0.45,0.33,0.260.19,0.17
• Reconstruction Time(S)：<60
• Weight：265kg
• Transport Package：Woodern Case
• Trademark：Healicom
• Origin：Jiangsu, China
• Production Capacity：1000units Per Year

Radiograph Mode  Digital Panorama,Corn Beam CT,Cephalometric ImagingAnode Voltage     50-90KVAnode Current    2-10mAExposure Time       Panorama17 CT20(Effective Exposure  8)Imag Dimension(FOV)CT12*8Pixel Size(mm)CT0.45,0.33,0.26,0.19,0.17Reconstruction Time(s)CT<60Weight(Kg)CT265



Specification

 PanoramaCTPart CTCephalometricH-X9010DPro-2D√   H-X9010DPro-2DE√  √H-X9010DPro-3D√√√ H-X9010DPro-3DE√√√√



Detailed Images

Brand New Experience for Dentist

Presently cone beam CT is the most promising and revolutionary device oforal and skull imaging equipment. Its X-ray generator will move around theobject for annular DR with low radiation, and after radiograph around theobject for times (180-360)the jointed data will be reconstructed by thecomputer to get the 3D image.The application of CBCT has epoch-makingmeaning to oral health.



 Incredible Cost Performance
Free Choice for CBCT,Panorama,Chalometric Imaging


Mainstream Configuration of Medium FOV, Flat Panel Detector
Effective FOV 12cmx8cm, Digital Imaging Chain, Fine Imaging, Full Image After OneTime Scanning



Remote Diagnosis, Faster After-sales Service
The specially designed system with high technology can check the machinerunning status completely. System diagnostic program enables the diagnosisand fault source positioning without specialized knowledge. The after-salesservice is of 365daysx 24hours with remote network technology.




Unique Algorithm,Perfect Showing
High Resolution Digital Image Chain
digitalization mouth unit adopts unique HRBPR image reconstruction andWEimage processing algorithm, and based on the super speed image reconstructionof CUDA technology, the NL-means image smoothing algorithm, and metal artifactsreduction algorithm etc, it provides the users 3D oral images with high resolution andhigh precision. Meanwhile, the applied pulse source technology can reduce theradiation level for patient and extend the liftime of X-Ray tube.



Precise 3D Diagnosis Software
The processing speed problem is solved by adoptingadvanced CUDA computing technology and thetomographic images will be generated after 10s.
After identify the metal area and reconstruct the imagefor second time, the metal artifacts will be reducedeffecively through second reconstruction overlying.The similarity of adjacent pixels is considered duringimage smoothing, which preserves the image detailseffectively at the same time.
The spin control precision of the system can reach0.01 based on the high performance FPGA and 5phase step motor.
The pulse X-Ray source and imaging flat panel canshutdown the X-ray synchronously within imagereading time to reduce the radiation level.



Clinical Images

 Reliable Image Showing
